ELECCTV New 8-Channel HD-TVI Security System 1080H Lite Video DVR Recorder with 1TB Surveillance Hard Disk Drive and (8) 1080p 1.3Megapixels Weatherproof Bullet Cameras, Smart Recording and Playback

Features:
Real-time monirtoring:
Have a composite video signal interface and support TV,VGA or HDMI output simultaneously.
Compression function:
Use H.264 video compression standard and G.711 audio compression standard and have high definition,low code rate of the video coding and the storage.
Recording function:
Support timing,linkage alarm,motion detection,SATA hard and local hard disk,DVR data backup and network backup.
Network functions:
Support TCP/IP, UDP, RTP/STSP, DHCP, PPPOE, DDNS, NTP P2P etc. Support real-time network monitoring, video playback, control and management functions; built-in WEB server, you can directly access through a browser.

DVR Specification:
AHD/TVI/CVBS: 8CH BNC, up to AHD/TVI 1080P
Output: 1CH CVBS(1.0vp-p,300ohms);1HDMI,1.3A support(1920x1080 resolutions);1CH, Resolution 1920x1080,1280x1024,1280x720,1024x768
Audio: 1CH RCA Input ,1CH RCA Output
Resolutions: 1080P(25/30FPS) 720P(25/30/50/60FPS)
FRMAE: 1-15fps
Video compression H.264(High profile/level 4.2)
Recording max: 8ch 720p/15fps 8ch half-1080p
Detection&Alarm: rigger events: Recording,Email;Motion detection: Zones 396(22x 18) Sensitivity 1-6(Level 6 is highest)
SYNC Playback: 1x1080H/720P/25fps
Back mode: USB.HDD.NETWORK BACKUP
Ethernet: 1 RJ45 10M/100M adaptive Ethernet interface.
Smart phone: IPHONE,ANDROID,IPAD

Camera Specification:
Image Sensor: 1 /4'' OV9732 Mega Sensor
Resolution: 1080P
Lens: 3.6mm
IR LEDs Amount: 18pcs SMD LEDs
IR Distance: up to 115ft
Waterproof Level: IP66
Power Supply: DC12V/2A

Package Contents:
1x 8CH DVR, 1TB Hard Drive
8x 1080P Bullet Cameras
8x 60ft Cables
2x 1 to 4 Splited Cable
2x Power supply for camera
1x Power supply for DVR

  • TitleELECCTV New 8-Channel HD-TVI Security System 1080H Lite Video DVR Recorder with 1TB Surveillance Hard Disk Drive and (8) 1080p 1.3Megapixels Weatherproof Bullet Cameras, Smart Recording and Playback
  • ManufacturerELECCTV
  • BindingElectronics
  • ProductGroupWireless
  • ItemPartNumber108BC15B-1TB-e
  • ModelELECCTV-CVK-108BC15B-1TB
  • UPCs520067417110
  • EANs0520067417110
